J100-2FiveS-001G-60BZ-E24Encoder of JD Technology
outputABZ generates direction-recognizable counting pulses by rotating grating discs and optocouplers.
Axle aperture:08-10-12-14-Fifteen- 18-20-24-25
Parameters: Number of pulses10cpr-5000cprOptional,working voltageDC5V-30Vpower supply,Maximum mechanical speed15000 rpm, response frequency: 0-300 KHz, consumption current: <150MA.
Output:output circuitYesNPN(PNP)Open-circuit output type of collector\ Voltage type, complementary type and long-line driving type（RS422)
Purpose:Servo motors, CNC machine tools, elevators, door machines, pipe benders, textile equipment
