HTR-6C-500-2-HL-SA50 adopts Taiwan technical encoder

HTR-6C-500-2-HL-SA50UseTaiwan Technological Encoder

outputABZ,The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.

axis/Aperture:06-08-10mm

Stainless steel shrapnel fixation for encoder body

pulse1-3600Signal output:TLLandHTLoutput

Voltage:DC 5V-30V

Parameters: The number of pulses is optional.DC5V-30VPower supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.

   Output:The output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type

   Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine, Loran

 HTR-6C-500-2-HL-SA50UseTaiwan Technological Encoder

outputABZ,The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.

axis/Aperture:06-08-10mm

Stainless steel shrapnel fixation for encoder body

pulse1-3600Signal output:TLLandHTLoutput

Voltage:DC 5V-30V

Parameters: The number of pulses is optional.DC5V-30VPower supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.

   Output:The output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type

   Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine, Loran
