outputABZ. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
axis/holePath: 4-5-6-8-9.525-10-12Mm
pulseOne hundred-Five hundredSignal output:TLLandHTLoutput
Voltage:DC5V-30V;
Parameters: The number of pulses is optional.DC5V-30V power supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN(PNP collector open-circuit output typevoltage type,complementary type and long-line drive type(RS422)General type
Uses: Textile, Servo Motor, CNC Machine Tool, Elevator, Door MachineoutputABZ. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
axis/holePath: 4-5-6-8-9.525-10-12Mm
pulseOne hundred-Five hundredSignal output:TLLandHTLoutput
Voltage:DC5V-30V;
Parameters: The number of pulses is optional.DC5V-30V power supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN（PNP collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Uses: Textile, Servo Motor, CNC Machine Tool, Elevator, Door Machine
