ET2R-1024/42/30VNew TechnologyHostEncoder
outputABZThe counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
2Number of pulses100-200-.512.1024.4096-5000-10000p/r
5Output Form:Open collector output, push-pull output, long-line drive output
New Structure FixedThe axle adopts a completely new clamping fixing method, which abandons the problem of old-fashioned top wire fixing not tightly.。 The encoder body is fixed by shrapnel.
use Path: Asynchronous Elevator Speed Control and Industrial Automation Control
· Appearance mode: computer socket side-outcable side-out
· Output mode: Voltage output, long-line drive output, open collector output, complementary output, etc. (optional)
Excellent Point: Stable performance, strong anti-interference
Parameters: The number of pulses is optional.DC5V-30VPower supply, maximum mechanical speedEight thousandturn/Response frequency:0-300KHzConsumption of current:<150MA。
Output:The output circuit hasNPN(PNP)Open-circuit output type of collector"Voltage type, complementary type and long-line driving type（RS422)General type
Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine
