E410.2Five0.824R15PP2 New Italian TechnologyEncoder
outputABZ. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Axle Diameter:4-5-6-8- 9-9.525-10-11-12-14-15Mm
Encoder body flange fixed;
pulse10-Three thousand and six hundredSignal output:TLLandHTLoutput
Voltage:DC5V-30V;
Parameters: The number of pulses is optional.DC5V-30V power supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN(PNP collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Purpose:Longitudinal and transverse cutting board saw"Servo Motor, CNC Machine Tool, Elevator, Door Machine
