DGS66-CZZ0-S02
outputABZ。 The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Axle Diameter:10-12-14-15MmThe synchronous flange of the encoder body is fixed.
pulse10-3600Signal output:TLLandHTLoutput
Voltage:DC5V-30V;
Parameters: The number of pulses is optional.DC5V-30VPower supply, maximum mechanical speedTwelve thousandturn/Response frequency:0-300KHzConsumption of current:<150MA。
Output:The output circuit hasNPN(PNP)Open-circuit output type of collector"Voltage type, complementary type and long-line driving type（RS422)General type
Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine
