844B-Z424D-0360Encoder Complete Substitute
outputABZ。 The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Outside diameter:52mmAxis diameter:8-9-9.525-10-12.7-14-15 mm,Flange connection
pulse2-5000Signal output:TLLandHTLoutput
Voltage:DC5V-30V;
Parameters: The number of pulses is optional.DC5V-30VPower supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Uses: Textile, Servo Motor, CNC Machine Tool, Elevator, Door Machine
