GHU925D1000-003EncoderComplete substitutes
DHU9_25//5GT9//D1000//G6R//U0***
outputABZThe counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
external diameterEighty-eightAxis aperture:20-22-24-25-28-30 mm
Parameters: Pulse number 1000 cpr-2000 cpr-2500 CPR is optional,Working voltage DC5V-30V power supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:output circuitYesNPN(PNP)Open-circuit output type of collector"Voltage type, complementary type and long-line driving type（RS422)General type
Purpose:Servo motors, CNC machine tools, elevators, door machines, pipe benders, textile equipment
