1024CPR Rotary Encoder Official Specification Document (For Toshiba Elevator)
1. Product Introduction
This rotary encoder is equipped with high-precision grating disc and optocoupler sensing structure. It outputs standard ABZ three-phase pulse signals, which can identify rotation direction and complete accurate counting and speed feedback. This model is specially designed and compatible for Toshiba elevator systems, and also suitable for various industrial automation equipment.
2. Special Parameters for Toshiba Elevator
-
Resolution: 1024 CPR
-
Main Output Signal: RS422 long-line driver output, Push-pull output, NPN open collector output
-
Working Voltage: DC 5V–30V
3. Full Technical Specifications
-
Optional Pulse Resolution: 10CPR ~ 5000CPR
-
Operating Voltage Range: DC 5V–30V wide voltage power supply
-
Maximum Mechanical Speed: 15000 RPM
-
Response Frequency: 0KHz – 300KHz
-
Working Current: ≤150mA
-
Output Circuit Type: NPN / PNP open collector, voltage output, complementary output, RS422 long-line driver
4. Core Product Advantages
-
Support ABZ phase direction judgment and high-precision pulse counting, stable signal and high recognition accuracy
-
Multiple output modes optional, compatible with most industrial controllers and drive systems
-
Wide voltage DC 5V–30V design, strong anti-interference ability, adapt to complex industrial working conditions
-
High response frequency and high mechanical speed, support high-speed equipment operation feedback
-
Low power consumption, stable performance, wear resistance and long service life
5. Application Scope
Widely applied in Toshiba elevator systems, elevator door motors, servo motors, CNC machine tools, pipe bending machines, textile machinery and other industrial automation equipment.
