UFO-MTwo-01-2Z1-B00ENew Metal MaterialHandheld Pulse Encoder,handwheel encoder
Characteristics
Hand artery impulse generator (thin type), metal gear;
Rotating feel clear;
Installation SizeFifty.8, 3-M3;
Drive output type, strong anti-interference ability;
Long-distance transmission;
It is used for zero correction and signal segmentation of NC machine tools and printing machinery.
Optional number of pulses
25, 100p/r
Electrical parameters
supply voltageDC+5V or 5~12V;
output voltageHigh level (> 85% Vcc) and low level (< 0.3V);
Consumption currentLess thanSix0mA;
Response frequency0~40KHz;
Circuit characteristicsC collector open circuit output, F complementary output, E voltage output, L long-line drive output
Environmental conditions
ambient temperature-20 C ~90 C;
Storage temperature- The temperature ranges from 30 to 85 C.
Working humidity -30-85%;
protectWaterproof, Oil-proof, Dust-proof IPForty-five
Mechanical parameters
Start-up Torque1 x 10-2
Carrier-to-air ratio0.5 + 0.1T
Normal mechanical speedLess than100rpm
Maximum mechanical speed Fifteen0RPM
working lifeMTBF (> MTBF)50000h (+25 C, 200rpm)
Anti-vibration50m/, 10_200Hz, 2h in XYZ direction
About weightZero point one5Kg
